Convert it to a trame application

In this hands on session, we will provide an empty VTK window along with some GUI control from Vuetify but you will have to edit the code to integrate the VTK code previously executed so it can run in your browser with all the control connected.

Option 1 (repo)

python ./code/04-visualization-3d/02-vtk-trame-edit.py

Option 2 (copy/paste)

Create file with content

Create a file 02-vtk-trame-edit.py and paste the content below into it.

#!/usr/bin/env python
# -*- coding: utf-8 -*-

from trame.app import get_server
from trame.ui.vuetify3 import SinglePageLayout
from trame.widgets import vuetify3 as v3, vtk as vtkw
from trame.decorators import TrameApp, change

from vtkmodules.vtkInteractionStyle import vtkInteractorStyleSwitch  # noqa
import vtkmodules.vtkRenderingOpenGL2  # noqa

from vtkmodules.vtkRenderingCore import (
    vtkRenderWindow,
    vtkRenderWindowInteractor,
    vtkRenderer,
)


def setup_vtk():
    renderer = vtkRenderer()

    renderWindow = vtkRenderWindow()
    renderWindow.SetOffScreenRendering(1)
    renderWindow.AddRenderer(renderer)

    interactor = vtkRenderWindowInteractor()
    interactor.SetRenderWindow(renderWindow)
    interactor.GetInteractorStyle().SetCurrentStyleToTrackballCamera()

    return renderWindow


@TrameApp()
class VtkApp:
    def __init__(self, server=None):
        self.server = get_server(server)
        self.render_window = setup_vtk()
        self._build_ui()

    @property
    def ctrl(self):
        return self.server.controller

    @change("u_range", "v_range")
    def on_change(self, u_range, v_range, **_):
        # make method call to vtk object
        self.ctrl.view_update()

    def _build_ui(self):
        with SinglePageLayout(self.server, full_height=True) as layout:
            with layout.toolbar.clear() as tb:
                tb.density = "compact"
                v3.VRangeSlider(
                    label="U",
                    v_model=("u_range", [-4.5, 4.5]),
                    min=-4.5,
                    max=4.5,
                    step=0.1,
                    density="compact",
                    hide_details=True,
                    classes="mx-4",
                )
                v3.VRangeSlider(
                    label="V",
                    v_model=("v_range", [0.05, 3.14159 - 0.05]),
                    min=0.05,
                    max=3.14159 - 0.05,
                    step=0.05,
                    density="compact",
                    hide_details=True,
                    classes="mx-4",
                )

            with layout.content:
                with v3.VContainer(fluid=True, classes="ma-0 pa-0 h-100"):
                    with vtkw.VtkRemoteView(
                        self.render_window, interactive_ratio=1
                    ) as view:
                        self.ctrl.view_update = view.update
                        self.ctrl.view_reset_camera = view.reset_camera


if __name__ == "__main__":
    app = VtkApp()
    app.server.start()

Run example

python 02-vtk-trame-edit.py

Result

Then with some edits you should get

Also the final code should be 45% smaller than the pure VTK version.
